| Specifications | Range | Best Accuracy |
| Model | 　 | UT51 |
| DC Voltage (V) | 200mV/2V/20V/200V/1000V | �(0.5%+1) |
| AC Voltage (V) | 200mV/2V/20V/200V/750V | �(0.8%+3) |
| DC Current (A) | 20uA/200uA/2mA/20mA/200mA/2A/10A | �(0.8%+1) |
| AC Current (A) | 200uA/2mA/20mA/200mA/2A/10A | �(1%+3) |
| Resistance (Ω) | 200Ω/2kΩ/20kΩ/200kΩ/2MΩ/20MΩ/200MΩ | �(0.8%+1) |
| Features | |
| Fused 10A Range | | √ |
| Transistor | | √ |
| Diode | | √ |
| Continuity Buzzer | | √ |
| Low Battery Display | | √ |
| Input Impedance for DC Voltage Measurement | 10MΩ | √ |
| Max. Display | 1999 | √ |
| General Characteristic� |
| Power | 9V Battery (6F22) |
| LCD Size | 65mm�33mm |
| Product Colour | Red and Grey |
| Product Net Weight | 560g (including holster) |
| Product Size | 190mm�88mm�34mm |
| Standard Accessories | Test Lead, Batteryl, Holster |
| Standard Individual Packing | Gift Box，English Manual |
| Standard Quantity Per Carton | 20 Pcs |
| Standard Carton Measurement | 535mm�362mm�385mm |
| Standard Carton Gross Weight | 20.5 Kg |
| Optional Accessories* | Clip-On Test Lead Light (UT-TL), Built-In Test Lead Light (UT-L1), Built-In Test Lead Light Plus (UT-L2) |
Product Manual (en)
-
Part No
UT51
-
Manufacturer
UNI-TREND TECHNOLOGY LTD.
-
Stock No
MJJD-811A
-
SKU No
238117
